The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5.1 inch 160x128 LCD Graphic Module/DFSTN-/RA6963/MCU/Arduino/Black Background, White Text HTM160128B-41W-A5P | Graphic LCD Module | 160x128 |
|
129.0x102.0x8.6 | 101.0x82.0 | 92.76x74.2 | 0.58x0.54 | 6H | white | 22PIN | MCU | RA6963 | -20~70℃ | 5.0V | RA6963 | |
| 5.1 inch 160x128 LCD Graphic LCD Module/RA6963/Arduino/White on Blue/Transmissive Polarizer HTM160128B-31W-A5P | Graphic LCD Module | 160x128 |
|
129.0x102.0x8.6 | 101.0x82.0 | 92.76x74.2 | 0.58x0.54 | 6H | white | 22PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | RA6963 | |
| 5.1 inch 160x128 LCD Graphic Module | FSTN+ | RA6963 | MCU | Arduino | Gray on White HTM160128B-31W-A5P | Graphic LCD Module | 160x128 |
|
129.0x102.0x8.6 | 101.0x82.0 | 92.76x74.2 | 0.58x0.54 | 6H | white | 22PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | RA6963 | |
| 5.1 inch 160x128 LCD Graphic Module | Yellow-Green Backlight | STN+ | RA6963 | MCU | Arduino HTM160128B-01Y-A5P | Graphic LCD Module | 160x128 |
|
129.0x102.0x8.6 | 101.0x82.0 | 92.76x74.2 | 0.58x0.54 | 6H | YG | 22PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | RA6963 | |
| 3.4-inch 160x32 LCD Graphic Module | RGB Red Green Blue Backlight | FSTN+ | MCU | Arduino ST7565R HTM16032B-35S-A5P | Graphic LCD Module | 160x32 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | R/G/B | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.4 inch 160x32 LCD Graphic Module | 16032 Graphic LCD Module | STN+ | MCU | Arduino | 5.0V HTM16032B-11Y-A5P | Graphic LCD Module | 160x32 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.4" 160x32 LCD Graphic Module | Blue on Gray | STN+ | MCU | Arduino HTM16032B-11W-A5P | Graphic LCD Module | 160x32 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.4 inch 160x32 LCD Graphic Module | White on Black | DFSTN- | MCU | Arduino HTM16032B-41W-A5P | Graphic LCD Module | 128x64 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.4" 160x32 LCD Graphic Module | Gray Text on White Background | FSTN+ | MCU | Arduino HTM16032B-31W-A5P | Graphic LCD Module | 160x32 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | White | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.4" 160x32LCD Graphic Dot Matrix Module | Yellow-Green Backlight | STN+ | MCU | Arduino HTM16032B-01Y-A5P | Graphic LCD Module | 160x32 |
|
116.0x35.0x13.6 | 83.0x18.6 | 80.0x15.9 | 0.50x0.50 | 6H | YG | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R |
