The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.7 inch | 128x64 Graphic LCD Display Module | White background with grey text 128x64 Graphic LCD Module HTM12864C02-31W-A3P | Graphic LCD Module | 128x64 |
|
40.6x32.2x11.0 | 37.0x23.3 | 33.26x20.48 | 0.26x0.32 | 6H | white | FFC-18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 3.2 inch 128x64 graphic dot matrix module/red, green and blue backlight/Chinese character library/FSTN fully transmissive LCD/Arduino HTM12864Z-35S-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 6H | R/G/B | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |
| 3.2 inch 128x64 yellow-green backlight graphic LCD module | Graphic COB module | STN+gray background | Arduino HTM12864Z-11Y-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 0.52x0.48 | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |||
| 3.2 inch monochrome graphic LCD module | 128x64 graphic LCD module | ST7920 | MCU interface | for Arduino HTM12864Z-11W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |
| 3.2 inch Black 128x64 Graphic LCD Display Module | DFSTN Negative Display | ST7920 | Arduino HTM12864Z-41W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |
| 3.2 inch 128X64 monochrome graphic dot matrix module LCM/white background with gray text/ST7920 control chip/Arduino HTM12864Z-31W-A5P | Graphic LCD Module | 128X64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | |
| 3.2" Graphic 128x64 LCD | ST7920 | Graphic LCD Display Module | 5.0v | Arduino HTM12864Z-01Y-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x10.0 | 71.4x38.7 | 66.52x33.24 | 0.52x0.48 | 6H | YG | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7920 | ||
| 2" Graphic Transmissive LCD | 128X64 Graphic LCD Module | FSTN+ | RGB | Arduino HTM12864F-35S-A5P | Graphic LCD Module | 128x64 |
|
54X50X6.5 | 43.5x29 | 40.92x24.92 | 0.32x0.39 | 6H | R/G/B | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 2-inch LCD graphic display module | 128x64 dot matrix graphic LCD module | STN gray film yellow-green backlight | arduino HTM12864F-11Y-A5P | Graphic LCD Module | 128x64 |
|
54X50X6.5 | 43.5x29 | 40.92x24.92 | 0.32x0.39 | 6H | YG | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 | |
| 2.0-inch LCD128x64 graphic dot matrix module/STN gray film white backlight/Arduino/5.0V HTM12864F-11W-A5P | Graphic LCD Module | 128X64 |
|
54X50X6.5 | 43.5x29 | 40.92x24.92 | 0.32x0.39 | 6H | white | 20PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 5.0V | KS0108 |
